Servicing Fan Modules 127
FIGURE: Removing a Fan Module
Related Information
■ “Extend the Server to the Maintenance Position” on page 63
▼ Install a Fan Module
Caution – To ensure proper system cooling, be certain to install the replacement fan
module in the same slot from which the faulty fan was removed.
1. With the top cover door open, install the replacement fan module into the
server.
The fan modules are keyed to ensure that they are installed facing in the correct
direction.
