Servicing Hard Drives

77

Four-Drive Capable Backplane
Configuration Reference

The following table shows the physical hard drive locations in a four-drive capable
backplane.

The following table matches the FRU names and the default OpenBoot
PROM/Solaris drive pathnames with the physical drive locations in a four-drive
capable backplane.

Related Information

“Install a Hard Drive” on page 73

“Remove a Hard Drive” on page 71

“Eight-Drive Capable Backplane Configuration Reference” on page 78

“Sixteen-Drive Capable Backplane Configuration Reference” on page 79

TABLE:

Physical Drive Locations in a Four-Drive Capable Backplane

DVD

HDD0

HDD1

HDD2

HDD3

TABLE:

Physical Drive Locations, FRU Names, and Default Drive Pathnames for a
Four-Drive Capable Backplane

Physical Location

FRU Name

OpenBoot PROM/Solaris Default Drive Pathname

HDD0

/SYS/HDD0

c0::dsk/c1t0d0

HDD1

/SYS/HDD1

c0::dsk/c1t1d0

HDD2

/SYS/HDD2

c0::dsk/c1t2d0

HDD3

/SYS/HDD3

c0::dsk/c1t3d0

DVD

/SYS/DVD
