Sensor Installation and Connection 3-11
Gathering Tools and Equipment
Gather the following tools for the installation:
 Battery-powered hammer drill with assorted bits – including
the following at a minimum:
 ¼-inch (6-mm) x 6-inch (150-mm) masonry bit
 3/8-inch(10-mm) x 4-inch (100-mm) [minimum length]
masonry bit
 5/16-inch (8-mm) carbide-tipped bit
 Heavy 4-poound (1.5-Kg) hammer
 Rubber mallet
 24-inch (610-mm) carpenter’s level
 Nut driver or socket set (English plus 13-mm for canister
hardware)
 Wrenches (English plus 13-mm for canister hardware)
 Screwdrivers (flathead and Phillips head of assorted sizes)
 Thread tap compatible with the thread spec on the monitor
mounting stud (3/8-in. standard)
 Diagonal wire cutters

Folding carpenter’s rule with a brass slide
 Mastic tape (ADS p/n 507193) or rubber coaxial stretch tape
Assembling the Ring
The flow sensors mount to a stainless steel ring for installation in
the pipe. Several different ring sizes exist, and each ring is
adjustable within about 3 inches (76 mm) to fit pipes of different
diameters. Assemble the ring in the following way:
Note: These instructions generally apply to overlapping
rings. However, the 6-inch (152-mm), 8-inch (178- to
211-mm),
10-inch (229- to 262-mm), and 12-inch (279 to
312-mm) rings do not have an overlapping section.
