6-12 ADS TRITON+ Manual
Assigning and Editing Devices
As part of entering the monitor and monitoring point information,
you must assign and edit the devices for each monitoring point.
Most devices should require only minimal, if any, modification to
the associated parameters.
1. Click on the browse button located to the right of the Devices
list box.
The Available Device list box displays the devices applicable to the
TRITON+ monitor series.
Available Devices list for a TRITON+
2. Select the devices that you want to assign to Monitoring Point
1. To select multiple devices simultaneously, press and hold
down the Control (Ctrl) key while selecting the individual
devices. To choose consecutive devices in the list, select the
first device you want to assign, press and hold down the Shift
key, and then click on the last device you want to include.
