Configuration and Activation 6-11
2. Enter the distance from the bottom of the pipe to the crown
(i.e., top or peak) in the Height field.
3. Enter the horizontal distance across the widest portion of the
pipe in the Width field.
The Description field indicates the physical description for the
monitoring point based on the selected pipe type and dimensions
(height and width).
4. Enter the factor by which the monitor should multiply the peak
velocity to determine the average velocity for calculating the
flow rate in the Gain field. ADS recommends leaving the
default 0.90 setting for Gain.
5. Enter the depth of the silt at the bottom of the pipe at the
monitoring point in the Silt field.
6. (optional) Click on the Display button to show a simple
illustration of the pipe based on the current parameters.
7. Assign the appropriate devices to the monitoring point, and edit
each device as necessary. Refer to Assigning and Editing
Devices on page 6-12 for more information and instructions.
8. (applies only to a second monitoring point) Click on the
Monitoring Point 2 tab, and repeat steps 1 through 7.
9. Click on the Save button to store the new information and
changes to your local directory or network.
Note: Once you have finished entering and/or editing the
monitor and monitoring point, you must activate (or
reactivate) the monitor.
