Specifications A-11
ExPAC (ADS p/n 8000-0377)
The ExPAC (External Power and Communication unit) enables the
TRITON+ to receive power from an external DC source and
supports Modbus communications.
Enclosure Rectangular, ABS Plastic, DIN rail or wall mount,
IP20
Dimensions 5.7 inches (145 mm) wide x 3.6 inches (91 mm)
high x 1.6 inches (41 mm) deep
Weight 0.55 pounds (0.25 kg)
Operating
Temperature
-4 ° to 122° F (-20° to 50° C)
External Power Requires DC power input between 9 to 36 volts
and a minimum of 15 watts
I.S. DC output of 9 to 11.8 volts, 500 mA
Connectors One RS-485 (3 terminals), one RS-232 (DB9),
one USB type B, one 9-to-36-volt DC input (3
terminals), monitor communications (5 terminals),
and one DC out (3 terminals)
Certifications Associated Apparatus certification for use with
approved equipment in Zone 0 (Class I, Division
1, Groups C & D, in the U.S.) and Zone 0 in the
EU via SIRA/ATEX
Sira 09ATEX2027X, IECEX SIR09.0020X,
CSA 2013 2671180
