A-6 ADS TRITON+ Manual
Peak Doppler Velocity
Range -30 to 30 feet per second (-9.1 to 9.1 m/sec)
Deadband Extending 1.0 inch (25 mm) up from the bottom of
the sensor
Frequency 250 kHz – 1 MHz
Resolution 0.01 feet per second (0.003 m/sec)
Accuracy +/- 0.2 ft/sec (0.06 m/sec) or 4% of actual peak
velocity (whichever is greater) in flow velocities
from -5 to 20 ft/sec (-1.52 to 6.10 m/sec)
Pressure Depth
Pressure
Range
0.0 to 5.0 PSI (0.0 - 0.34 Bar): up to 11.5 feet (3.5
m)
0.0 to 15.0 PSI (0.0 - 1.03 Bar): up to 34.5 feet
(10.5 m)
0.0 to 30 PSI (0.0 – 2.07 Bar): up to 69.0 feet
(21.0 m)
Pressure
Accuracy
0 - 5.0 PSI (0 - 0.34 Bar): +/- 1.4 inches (36 mm)
0 - 15.0 PSI (0 - 1.03 Bar): +/- 4.1 inches (104
mm)
0.0 to 30 PSI (0.0 – 2.07 Bar): +/- 8.3 inches (211
mm)
Pressure
Resolution
0.01 inches (0.25 mm)
