Figure 4-12. Spring Extended Spool Positioner
SPRING EXTENDED SPOOL POSITIONER
Item
No. Part
No.
Description
Quality
Per Section
Item
No. Part
No.
Description
Quality
Per Section
K-40002
20812-001
1608-001
12034-001
3731-102
12301-001
1
2
3
4
5
REPLACEMENT KIT (Contains all items listed below )
ADAPTER
SPRING
BONNET
SCREW, ¼-20 by
SPACER, Retainer
1
1
1
2
1
K-40006
11793-005
3731-101
20852-001
2973-001
1838-001
20853-001
1
2
3
4
5
6
Figure 4-13. 3-Position Detent Positioner
3-POSITION DETENT POSITIONER
REPLACEMENT KIT (Contains all items listed below)
BONNET
SCREW, HSHC ¼-20
SLEEVE
BALL, Steel, .250 dia.
SPRING
HOLDER, Ball
1
2
1
2
1
1
4-10
