8.1
H YDRAULIC S UB- A SSEMBLY:
S HOWING A UXILIARY H YDRAULICS AND E LECTRICS
Item
1
5
6
7
8
9
10
11
12
13
14
is
16
17
18
19
21
22
26
27
29
35
Qty.
1
6
2
5
1
6
5
4
1
1
1
1
2
3
3
3
1
1
1
1
AR
1
Description of Part
Hose Carrier
Ty-Rap
Hose Assembly
Strain Relief Fitting
Tube Assembly
Cushion Clamp, 1 /
8
"
Cushion Clamp, 3 /
4
"
Bulkhead Fitting
Tube Assembly
Tube Assembly
Tube Assembly
Tube Assembly
Straight Thread Bulkhead Fitting
Stackbolt
Tube Clamp
Coverplate
Tube Assembly
Hose Guide Bracket
Hose Sheave pin
Hose Sheave
Mystik Tetrimoly Grease
Aux. Boom Wiring Harness
Item
36
37
38
39
44
45
46
47
48
49
50
51
52
53
55
56
57
58
59
60
61
62
102
Description of Part
Cushion Clamp, 1 /
2
"
Cushion Clamp, 7 /
8
"
Hose Assembly
Hose Assembly
3 Compression Spring
90 Degree Bulkhead Fitting
Spring Retainer
Cable Take-up Support
Cable Take-up Weldment
Hose Take-up Weldment
Hose Assembly
Clamp
Base Plate
Cover Plate
Male Hydraulic Coupler
Dust Cap
Straight Thread Bulkhead fitting
Pipe Bushing, 1 /
2
X 3 /
8
Female Hydraulic Coupler
Dust Plug
Receptacle Bracket
Six Contact Receptacle
Hose Assembly
Qty.
8
4
2
2
2
3
1
1
2
1
1
1
1
1
1
2
2
1
1
1
1
1
