Stage 3
Adjust the bearing pad shims on the rear top and side of boom-section 2.
Install front top chain rollers to boom-sections 2 and 3.
Install the hoses to the bulkhead fittings on the hose take-up weldment.
F
RONT,
C
OMPLETE
B
OOM
A
SSEMBLY
Install the cushion clamps around the hoses on boom-section 1.
R
EAR
C
OMPLETE
B
OOM
A
SSEMBLY
Stage 4
Connect the crowd cylinder and support to boom-sections 1 and 2.
C
OMPLETE
B
OOM
A
SSEMBLY
Attach the crowd cylinder hose assembly.
F
ORM
N
o.
29702
l
l
l
l
l
544C/544D B
OOM
M
AINTENANCE
➝
1.
2.
3.
5.
B
OOM
-S
ECTION
3: R
EAR
V
IEW
➝
1.
2.
R
EAR,
C
OMPLETE
B
OOM
A
SSEMBLY
9.23
