Page 311
3.5
B
OOM-
S
ECTION
1 W
EAR
P
ADS
Item
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
Qty.
2
2
4
4
8
8
8
6
4
2
2
2
2
2
2
6
6
2
2
1
1
1
Description of Part
Hex HD Cap Screw,
1
/
2
-13 X 1, GR5
Lockwasher,
1
/
2
"
Hex HD Cap Screw,
3
/
8
-24 X 1-
3
/
4
, GR5
Hardened Washer,
3
/
8
"
Hex HD Cap Screw,
3
/
8
-24 X
3
/
4
, GR5
Flat Washer,
3
/
8
Shim
Shim Spacer
Bearing Pad
Bearing Pad Support
Bearing Pad
Bearing Pad
Shim Spacer
Shim
Bearing Pad Support
Hardened Washer,
1
/
2
"
Hex HD Cap Screw,
1
/
2
-20 X 2-
1
/
2
, GR5
Bushing
Lube Filling, 90°,
1
/
8
"
Boom Base Pin
Hex HD Cap Screw,
5
/
8
-11 X 6, GR8
Hex Nut,
5
/
8
-11
