Reassembling: Ensure that the
two flags on the media sensor are
correctly positioned.
7 Pull the media sensor straight out towards you, freeing it from the underside of the entry
platen.
8 Cut the plastic tie that fastens the
mediaĆsensor cable to the underside of
the entry platen.
9 Lift the media sensor and cable clear of
the plotter
Plastic tie
Take care not to cut the
mediaĆsensor cable itself.
C A U T I O N
6-23 Removal and Replacement C4705-90000
