HP 750 - Manual (Page 59)

1 Read ESD Precautions ' page 6Ć3.
2 Unscrew the SIMM cover at the back of
the plotter and remove it.
3 Locate the DRAM SIMM slots, using the
second from the right first.
4 Hold the module with its nonmetallic edge
towards you and the small notch down.
5 Press the nonmetallic edge to the right,
and remove the module from the slot.
RAM
POST
CODE
Notch
6-7 Removal and Replacement C4705-90000
Removing a Memory Module (DRAM/ROM SIMM)
The user may have installed an optional DRAM/ROM SIMM in the plotter. Perform the
following procedure, if you need to remove it.
