HP 30 HP30 User Manual
Page 72
Chapter 5 - Parameter List
5-12
Keypad Display
Setting Range
Code
Description
LCD
7-Segment
LCD
7-Segment
Units
Factory
Default
Adj.
During
Run
Page
I/O-26
Deceleration Time 1
for Step Frequency
Dec time-1
26
0 to 6000 [sec]
0.1
20.0 [sec]
Yes
I/O-27 Acceleration Time 2
Acc time-2
27
0 to 6000 [sec]
0.1
30.0 [sec]
Yes
I/O-28 Deceleration Time 2
Dec time-2
28
0 to 6000 [sec]
0.1
30.0 [sec]
Yes
I/O-29 Acceleration Time 3
Acc time-3
29
0 to 6000 [sec]
0.1
40.0 [sec]
Yes
I/O-30 Deceleration Time 3
Dec time-3
30
0 to 6000 [sec]
0.1
40.0 [sec]
Yes
I/O-31 Acceleration Time 4
Acc time-4
31
0 to 6000 [sec]
0.1
50.0 [sec]
Yes
I/O-32 Deceleration Time 4
Dec time-4
32
0 to 6000 [sec]
0.1
50.0 [sec]
Yes
I/O-33 Acceleration Time 5
Acc time-5
33
0 to 6000 [sec]
0.1
40.0 [sec]
Yes
I/O-34 Deceleration Time 5
Dec time-5
34
0 to 6000 [sec]
0.1
40.0 [sec]
Yes
I/O-35 Acceleration Time 6
Acc time-6
35
0 to 6000 [sec]
0.1
30.0 [sec]
Yes
I/O-36 Deceleration Time 6
Dec time-6
36
0 to 6000 [sec]
0.1
30.0 [sec]
Yes
I/O-37 Acceleration Time 7
Acc time-7
37
0 to 6000 [sec]
0.1
20.0 [sec]
Yes
I/O-38 Deceleration Time 7
Dec time-7
38
0 to 6000 [sec]
0.1
20.0 [sec]
Yes
Frequency 0
Current 1
Voltage 2
DC link Vtg
3
I/O-40
FM (Frequency Meter)
Output Selection
FM mode
40
Torque 4
- Frequency Yes
I/O-41 FM Output Adjustment
FM adjust
41
10 to 200 [%]
1
100 [%]
Yes
6-2
I/O-42 Frequency Detection Level
FDT freq
42
0 to FU1-20
0.01 30.00 [Hz] Yes
I/O-43
Frequency Detection
Bandwidth
FDT band
43
0 to FU1-20
0.01 10.00 [Hz] Yes
6-2
FDT-1 0
FDT-2 1
FDT-3 2
FDT-4 3
FDT-5 4
OL 5
IOL 6
Stall 7
OV 8
LV 9
OH 10
Lost Command
11
Run 12
Stop 13
Steady 14
INV line
15
COMM line
16
Ssearch 17
I/O-44 Multi-Function Auxiliary
Contact Output Define
(AXA, AXC)
Aux mode
44
Step pulse
18
- Run Yes
6-2
