2-1
CHAPTER 2 - OPERATION
The ACtionMaster series inverter has seven parameter groups separated according to their applications as indicated in the
following table.
The ACtionMaster series inverter provides two kinds of keypad. One is of 32-character alphanumeric LCD keypad and the
other is of 7-Segment LED keypad.
2.1 Parameter Groups
Parameter
Group
LCD Keypad
(Upper left Corner)
7-segment Keypad
(LED is lit)
Description
Drive Group DRV ‘DRV’ LED
Command Frequency, Accel/Decel Time etc.
Basic Parameters
Function 1 Group FU1 ‘FU1’ LED
Max. Frequency, Amount of Torque Boost etc.
Basic Related Parameters
Function 2 Group FU2 ‘FU2’ LED
Frequency Jumps, Max./Min. Frequency Limit etc.
Basic Application Related Parameters
Input / Output
Group
I/O ‘I/O’ LED
Multi-Function Terminal Setting, Auto Operation etc.
Parameters needed for Sequence Operation
Sub-Board Group EXT ‘EXT’ LED Displayed when Sub-Board is Installed.
Option Group COM ‘I/O’ + ‘EXT’ LED Displayed when Option Board is Installed.
Application Group APP
‘FU2’ + ‘I/O’ + ‘EXT’
LED
Traverse, MMC (Multi-Motor Control), Draw etc.
Application Related Parameters
Refer to the function descriptions in Chapter 6 for detailed description of each group.
