HEIDENHAIN TNC 426, TNC 430 377
1
0
.8 A
d
ditional F
unctions
Nominal position in the REF system,
240 1 1 X axis
2 Y axis
3 Z axis
4 A axis
5 B axis
6 C axis
7 U axis
8 V axis
9 W axis
Nominal positions in the input
system, 270 1 1 X axis
2 Y axis
3 Z axis
4 A axis
5 B axis
6 C axis
7 U axis
8 V axis
9 W axis
Status of M128, 280 1 - 0: M128 inactive, -1: M128 active
2 - Feed rate that was programmed with M128
Triggering touch probe, 350 10 - Touch probe axis
11 - Effective ball radius
12 - Effective length
13 - Radius setting ring
14 1 Center misalignment in ref. axis
2 Center misalignment in minor axis
15 - Direction of center misalignment compared with 0°
position
Tool touch probe 130 20 1 Center point X-axis (REF system)
Group name, ID No. Number Index Meaning
