376
10 Programming: Q Parameters
1
0
.8 A
d
ditional F
unctions
0: mirroring not active
+1: X axis mirrored
+2: Y axis mirrored
+4: Z axis mirrored
+64: U axis mirrored
+128: V axis mirrored
+256: W axis mirrored
Combinations = sum of individual axes
4
1
Active scaling factor in X axis
4
2
Active scaling factor in Y axis
4
3
Active scaling factor in Z axis
4
7
Active scaling factor in U axis
4
8
Active scaling factor in V axis
4
9
Active scaling factor in W axis
5
1
3D ROT A axis
5
2
3D ROT B axis
5
3
3D ROT C axis
6
-
Tilted working plane active / inactive (-1/0)
Active datum shift, 220
2
1
X axis
2
Y axis
3
Z axis
4
A axis
5
B axis
6
C axis
7
U axis
8
V axis
9
W axis
Traverse range, 230
2
1 to 9
Negative software limit switch in axes 1 to 9
3
1 to 9
Positive software limit switch in axes 1 to 9
Group name, ID No.
Number
Index
Meaning
