HEIDENHAIN TNC 426 (280 476) User Manual
Page 286
HEIDENHAIN TNC 426, TNC 430
259
8.4 Cy
cles f
or milling poc
k
e
ts, st
uds and slots
7
7
7
7
Rounding off radius
: Radius for the pocket corners.
If Radius = 0 is entered, the pocket corners will be
rounded with the radius of the cutter.
Calculations:
Stepover factor k = K x R
K:
is the overlap factor, preset in machine parameter 7430, and
R
is the cutter radius
