BlackDiamond 8800 Series Modules
BlackDiamond 8800 Series Switches Hardware Installation Guide 40
Port LEDs on PoE Modules (G48P, G48Pe, and G48Tc or G48Te2 with S-POE Card)
This section describes the port LEDs for BlackDiamond 8800 series I/O modules that support PoE.
These include the following modules:
● G48P
● G48Pe
● G48Tc I/O module with an installed S-POE card
● G48Te2 I/O module with an installed S-POE card
Port LEDs on these modules indicate the status of the inline power delivered through the ports.
Table 7 describes the LED meanings for each port on the PoE-capable I/O modules.
Table 7: Port LEDs for the PoE-capable I/O Modules
LED Color Indicates
Port with power enabled Solid amber Link up
Amber blinking Activity
Slow amber blinking Port disabled
or
Link down
Blinking amber/green Power fault or insufficient power
Port with power disabled Solid green Link up
Slow green blinking Port disabled
Green blinking Activity
Off Link down
Blinking amber/green Power fault or insufficient power
