Connector Pinouts
BlackDiamond 8800 Series Switches Hardware Installation Guide 173
Connector Pinouts
Table 24 describes the pinouts for a DB-9 console plug connector.
Table 23: Specifications for the DC SSI PS Model #60021 (1200 W DC PSU)
Compatible with the BlackDiamond 8806 and BlackDiamond 8810 switches
Typical configuration 3 power supplies
Full configuration 6 power supplies
Input Nominal input voltage: –48 V
Voltage input range: –40.5 V
to –72 V
Input currents:
–40 V @ 35 A
–48 V @ 30 A
–60 V @ 23 A
Maximum in-rush current: Not more than 80 A for 5 ms
Input circuit protection: 50 A
Wire harness provided by Extreme Networks with each power supply.
Extreme Part# 4340-00028
Wire type: 8 AWG (10 mm
2 ) listed tray cable, copper-stranded rated @ 90 C
minimum
Connector: Molex connector PN 42816-0312
Connector pins: Molex connector pins PN 42815-0032
Output DC output: 48 V , 24 A/12 V , 4 A
DC output power (W): 1200 W
Operating conditions Operating temperature: 0° C to 40° C (32° F to 104 °F)
Operating humidity: 10% to 90% relative humidity, non-condensing
Operating altitude: 0 m to 3,000 m (0 ft to 9,850 ft)
Operational shock*: 30 m/s
2 (3 g), 60 shocks
Operational office vibration*: 5 to 100-5 Hz @ 2/10 G, 0 to peak, 1 oct/min
Operational random vibration*: 3 to 500 Hz @ 1.5 G rms
* Worst case operational condition; not for continuous operation under this
condition
Table 24: Pinouts for the DB-9 Console Connector
Function Pin Number Direction
DCD (data carrier detect) 1 In
RXD (receive data) 2 In
TXD (transmit data) 3 Out
DTR (data terminal ready) 4 Out
GND (ground) 5 -
DSR (data set ready) 6 In
RTS (request to send) 7 Out
CTS (clear to send) 8 In
