Repacking a BlackDiamond 8800 Series Chassis
BlackDiamond 8800 Series Switches Hardware Installation Guide
152
10
Place the packing foam material on top of the chassis as shown in
.
Figure 106: Packing Foam in the BlackDiamond 8806 Chassis Shipping Carton
11
Close the top flaps on the shipping carton and seal them with packing tape.
12
Secure the shipping carton with nylon straps (see
NOTE
Nylon straps are optional but are recommended by Extreme Networks for extra security during shipment. The
installation of nylon straps requires a crimping tool. If you do not have nylon straps and a crimping tool available to
secure the carton, the chassis can be shipped without the straps; however, it is critical that the clip locks be secure
before shipment.
Figure 107: Nylon Straps Around BlackDiamond 8806 Chassis Shipping Carton
EX_110B
EX_113
