Configuration
2013-08-14
55
5.2 Control Options
The Draco tera contains an internal CPU that allows you to control all
functions from any console without the need for an external CPU or media
control.
You have the following possibilities to access the Draco tera for
configuration and operation:
 via OSD
 via Java Tool
 via serial interface
Pos: 45 /806-IHSE/Konfiguration/480_Ansteuerung/480-xx/Ansteuerung via OSD @ 7\mod_1309937635540_6.doc @ 52920 @ 3 @ 1
5.2.1 Control via OSD
Via OSD (On-Screen-Display) you set the configuration of the Draco tera
operating system. The settings of the menu Configuration are described
below. All other menus are described in later chapters.
You have the following possibilities to enter the OSD of the Draco tera:
 via keyboard connected to the CPU board
 via keyboard connected to a CON unit of an extender
Entering OSD
1. Start Command Mode with the 'Hot Key' (see Chapter 5.1, Page 53).
2. Press to open OSD.
You will see a list of all available CPUs as a start menu.
3. Press to enter the main menu.
If the option Enable CPU Selection is activated in the menu
Configuration, first of all the selection list for switching CPU devices will
be opened. This list can be skipped by pressing the key .
Leaving OSD
 Press the key in the main menu or simultaneously
+ anywhere within the OSD.
The OSD will be closed without any further changes and the currently
active CPU connection will be displayed.
