3.7
Diagnostics and Status
Pos: 22 /806-IHSE/Beschreibung/Diagnose LEDs/480-xx @ 7\mod_1309934983180_6.doc @ 52622 @ 3 @ 1
3.7.1 Status LEDs
The Draco tera components are fitted with the following LEDs for overall
status indication:
CPU Board
Front View
