Troubleshooting
2013-08-14
199
Pos: 167 /806-IHSE/Hilfe im Problemfall/Störung an der Matrix/480-xx @ 7\mod_1309944331383_6.doc @ 54040 @ 2 @ 1
9.6 Failure at the Matrix
Diagnosis Possible Reason Measure
Serial control
impossible or
only restrictedly
possible. Different Baud rate of
CPU and matrix.  Adapt Baud rate in the matrix
and in the CPU (see Chapter
5.3.2, Page 72).
Serial control via
RJ45 port not
possible. Wrong network cable.  Use a crossed network cable
Port definitions
as USB 2.0
invalid. Restart of the matrix not
yet completed.  Do a restart.
