Draco tera
20
2013-08-14
Status LEDs on CPU board:
Pos. LED Status Description
White CPU board is in registration process
Blue
flashing Registration at the matrix is started
Red
flashing Registration in progress
Green
flashing Operating condition
1 Status 1
Green CPU board de-registered
White CPU board is in registration process
Red
flashing Registration at the matrix is started
2 Status 2
Off Operating condition
Due to variations in LED type "white" might also appear as light purple or
light blue.
