Specifications
2013-08-14
183
Maximum Acceptable Cable Length
Type of cable 1.25 Gbps 3.125 Gbps
Single-mode 9μm 10,000 m (32,800 ft) 5,000 m (16,400 ft)
Multi-mode 50μm (OM3) 1,000 m (3,280 ft) 500 m (1,640 ft)
Multi-mode 50μm 400 m (1,300 ft) 200 m (650 ft)
Multi-mode 62.5μm 200 m (650 ft) 100 m (325 ft)
If you use single-mode SFPs with multi-mode fibers, you normally can
increase the maximum acceptable cable length.
Type of Connector
Connector LC Connector
Pos: 131 /806-IHSE/Technische Daten/Verbindungskabel/Koaxial @ 7\mod_1309942381352_6.doc @ 53747 @ 3 @ 1
7.2.3 Coaxial
A point-to-point connection is necessary.
Type of Interconnect Cable
Cable Type Specifications
Mini coaxial cable AWG 18 RG 6
impedance 75 Ω
Maximum Acceptable Cable Length
Band Width Maximum Acceptable Cable Length
0.270 Gbit/s 400 m (1,312 ft)
1.485 Gbit/s 140 m (459 ft)
2.970 Gbit/s 120 m (394 ft)
Type of Connector
Connector Mini BNC connector
