Installation
2013-08-14
51
1
Dual-Head source (computer, CPU)
2 CPU
unit
3 Interconnect
cable
4
Draco tera matrix (master matrix)
5
Draco tera matrix (slave matrix)
6
Network connection master / slave(s)
7 CON
unit
8
Console (2x monitor, keyboard, mouse)
