Page 17: Description
Description
2013-08-14
17
Pos: 17 /806-IHSE/Beschreibung/Geräteansichten/480-xx/Draco tera 80 Port @ 7\mod_1309934775696_6.doc @ 52586 @ 3 @ 1
3.6.3 Draco tera 80 Port
FIL
TER
T
OP
1
2
3
4
5
6
7
OK
HS
FAN TRAY
OK
HS
FAN TRAY
Front View
1
Slot for fan tray
2
Slot for power supply unit 1
3
Slot for I/O boards #1–10
4
Slot for power supply unit 2
5
Slot for CPU board
6
Slot for air filter
7
Slot for fan tray 2
