IEEE 488.2 and SCPI Command Operation Sorensen Ethernet Option
3-28 M130/131 Programming Manual
Command Description SCPI
:PORT
Set the network TCP/IP socket listening port.
Valid values are 1025 to 65535.
:PORT?
Returns the network TCP/IP socket listening
port.
:PRICONF
Sets Primary IP configuration.
0 = DHCP; 1 = DHCPAUTOIP; 2 = STATICIP
:PRICONF?
Returns currently set Primary IP configuration
0 = DHCP; 1 = DHCPAUTOIP; 2 = STATICIP
:SECCONF
Sets Secondary IP configuration.
0 = DHCP; 1 = DHCPAUTOIP; 2 = STATICIP
:SECCONF?
Returns currently set Secondary IP configuration.
0 = DHCP; 1 = DHCPAUTOIP; 2 = STATICIP
:TERM
Set the return string terminators to be used by
the device. The valid range is 1-4. Values
indicate the following terminator(s):
1 = 0x0d only (CR), 2 = 0x0a only (LF), 3 =
0x0d 0x0a (CR LF), 4 = 0x0a 0x0d (LF CR)
:TERM?
Returns the string terminators to be used by the
device.
Table 3-8 System Fault Registers
Bit Position Bit Weight Fault1–8 Fault9–16 Fault17–24 Fault25–31
7 128 Channel 8 Channel 16 Channel 24 not used
6 64 Channel 7 Channel 15 Channel 23 Channel 31
5 32 Channel 6 Channel 14 Channel 22 Channel 30
4 16 Channel 5 Channel 13 Channel 21 Channel 29
3 8 Channel 4 Channel 12 Channel 20 Channel 28
2 4 Channel 3 Channel 11 Channel 19 Channel 27
1 2 Channel 2 Channel 10 Channel 18 Channel 26
0 1 Channel 1 Channel 9 Channel 17 Channel 25
The M130 provides four System Fault Registers to allow the user to monitor the fault
status of a multiple-channel system. For example, the user may poll these registers to
quickly determine which channel generated an enabled GPIB or Ethernet service request.
The SYStem:FAULt? query returns 4 numeric values separated by commas. Each value is
the decimal equivalent of the total bit weights for that System Fault Register as described
in the table above.
