XR500 Series Canadian Programming Guide Digital Monitoring Products
69
APPENDIX
23.9 User Profiles Record
This User Profiles Record can be used as a tool when programming Devices, Profiles, Areas, and Output
Groups. Because these programming options are interrelated, use this sheet to plan the system before you
begin the installation and programming process.
Profile
# Profile Name
Arm/Disarm
Areas Access Areas
Output
Group Arm Disarm Alar
m Silence
Sensor Reset Door A
ccess
Armed Area Out
put
s On/Off
Zone St
at
us
Bypass Zones Zone Monitor System St
atus
System Test User
Pr
ofiles
User Codes Schedules Time Display Event
s
Servi
ce Request
Fire Drill Ex
tend Schedules
Temp User Code Ant
i-passback
Easy A
rm/Disarm
Shift/Time Access Re Arm Delay Sec Language
1 2 3 4 A
1 2 3 4 A
1 2 3 4 A
1 2 3 4 A
1 2 3 4 A
1 2 3 4 A
1 2 3 4 A
1 2 3 4 A
1 2 3 4 A
1 2 3 4 A
1 2 3 4 A
1 2 3 4 A
1 2 3 4 A
1 2 3 4 A
1 2 3 4 A
1 2 3 4 A
1 2 3 4 A
1 2 3 4 A
1 2 3 4 A
1 2 3 4 A
23.10 FA Series Transmitter Information
A House ID Number is like an address for FA Series wireless transmitters so they know with which panel
they should be communicating. The House ID Number is based on the last two digits of the panel primary
account number.
Be sure that the primary panel account number is programmed before programming any wireless
transmitters. Because the House ID is based on the account number, entering or changing the primary
account number after programming the transmitters requires you to reprogram all of the transmitters.
Cross Talk
If you have more than one account within a five-mile radius, there is a possibility that “cross talk” can
occur. “Cross talk” is when transmitters communicate with multiple panels when the transmitters have
the same House ID. If you have two panels within a five-mile radius that use wireless zones, be sure that
the last two digits of the account numbers are not the same.
For example, ABC Plumbing has a panel with an account number of 12345 that uses wireless zones. The
House ID for the wireless transmitters at ABC Plumbing is 45. Two blocks away, XYZ Printing has an
account number of 22345 and the panel also uses wireless zones. The House ID for the transmitters for
XYZ Printing is 45. Because the two accounts have the same last two digits in the account numbers, the
House ID is the same. Therefore, the wireless transmitters “cross talk” and report to both panels bearing
the same House ID.
To avoid “cross talking”, panels within a five-mile radius must not have the same two digits in the primary
account number. If a “cross talk” issue is already present, you must delete the wireless transmitter zones,
enter the proper account numbers, and then reprogram the wireless transmitters.
