XR500 Series Canadian Programming Guide Digital Monitoring Products
55
ZONE INFORMATION
19.11.7
BUTTON ACTION
yyy: XXXXXXXX
Button Action
This option specifies the Button Action for an individual key fob button. The
default action for the button selected is displayed. Press any Select key to
display the Button Action options. To view more options press COMMAND.
yyy = the name of the button being programmed (TOP, BTM, LFT, RGT).
BUTTON ACTION
ARM DIS TGL STA
ARM (Arm) - Arms selected areas and force arms bad zones.
DIS (Disarm) - Disarms selected areas.
TGL (Toggle Arm) - Toggles arm/disarm for selected areas and force arms bad
zones when arming.
STA (Status) - Causes the key fob LED to indicate the arm/disarm status of the
system.
BUTTON ACTION
PN PN2 EM EM2
PN (Panic) - Triggers a Panic zone type alarm with no restoral.
PN2 (Panic 2) - Triggers a Panic zone type alarm with no restoral when pressed
simultaneously with any other Panic 2 button. No action occurs when pressed
alone.
EM (Emerg) - Triggers an Emergency zone type alarm with no restoral.
EM2 (Emerg 2) - Triggers an Emergency zone type alarm with no restoral when
pressed simultaneously with any other Emergency 2 button. No action occurs
when pressed alone.
BUTTON ACTION
OUT RST UN
OUT (Output) - Causes an output to turn on steady, pulse, momentary, toggle or
off.
RST (Sensor Reset) - Causes the panel to perform a standard Sensor Reset.
UN (Unused) - The button is not used and performs no action.
19.11.8
BUTTON
PRESS TIME: XXXXX
Button Press Time
This option specifies the amount of time (SHORT or LONG) the user must press
the button before the key fob sends a message to the wireless receiver. The
default press time displays. Press any Select key to set the Button Press Time
for Arm, Disarm, Toggle, Status, Output, and Sensor Reset.
Note: The Button Press Time is not programmable on Panic (PN or PN2),
Emergency (EM or EM2) or Unused (UN) zones. For those zones the button press
time is always two (2) seconds.
PRESS TIME:
SHORT LONG
SHORT - Press the button for one-half (1/2) second to send the message to the
wireless receiver.
LONG - Press the button for two (2) seconds to send the message to the wireless
receiver.
19.11.9
ARM/DIS AREAS:
Arm/Disarm Area Selection
In an Area system or Home/Sleep/Away with Guest system, this specifies the
areas to be armed/disarmed by the Key Fob button being programmed. To
select an area between 1 and 32, enter the area number using the keypad digit
keys. Default is no areas enabled.
In order to arm or disarm selected areas, the Profile assigned to the User
Number needs to have the same area numbers selected. Any area may be
selected at Arm/Disarm Areas but only matching area numbers are armed or
disarmed when the specific button is pressed. For example, in Areas selection,
areas 1, 3, and 7 are selected. In the User Profile Arm and Disarm Areas, areas
1, 2, 4, and 7 are selected. When the user presses the button to Arm or Disarm
area(s), only matching areas 1 and 7 Arm/Disarm.
Note: When more areas are selected at Arm/Disarm Areas than are authorized
in the User Profile, in the future the user can be given access authority to
additional areas through the User Profile without requiring additional panel
programming to select Arm/Disarm Areas. See User Profiles in the Appendix or
refer to the XR500 Series Canadian User’s Guide (LT-0683CAN).
