Digital Monitoring Products XR500 Series Canadian Programming Guide
64
APPENDIX
Serial Number
This number is the network communicator serial number. Reference this number for communicator date-
of-manufacture, hardware version, etc. Press any top row Select key to display the Serial Number. Press
the COMMAND key to view the next prompt.
Current Flash
This option displays Flash 1 or Flash 2 indicating which physical flash chip the panel is currently using. Press any
top row Select key to display the current flash information. Press the COMMAND key to view the next prompt.
Communication Status
This option tests the individual components of cellular or network communication. The displayed results
are shown below.
Cellular Results:
Successful Display Failure Display
MODEM OPERATING NO MODEM FOUND
SIM CARD READ NO SIM CARD
TOWER DETECTED NO TOWER
SIM REGISTERED NOT REGISTERED
This displays the cellular signal strength of the nearest tower for the SIM card carrier.
The ▐’s represent the signal strength 0-7. Select YES to continue through the remaining
component tests. Select NO to stop testing and return to the COMM STATUS prompt.
Successful Display Failure Display
APN ACCEPTED APN ERROR
COMM PATH GOOD NO ACK RECEIVED
Network Results:
Successful Display Failure Display
LINK OK LINK ERROR
DHCP OK DHCP ERROR
GATEWAY FOUND NO GATEWAY
DEST FOUND NO DESTINATION
COMM PATH GOOD NOT CONNECTED
NO ACK RECEIVED
Cellular Signal Strength (CELL SIGNAL)
This option provides a way to test the cellular signal strength of the nearest tower
for the SIM card carrier. Press any top row Select key to display cell signal strength.
The X’s represent the numerical value of the cell signal strength in -dBm. The ▐’s
represent the signal strength 0-7.
Email Status
The Email Status menu, located in Diagnostics, tests each component of the panel’s e-mail
communication. The test proceeds until the first component failure or until all components have been
tested with positive results. The test screen displays after each component and displays for two seconds
or until the CMD key has been pressed. The displayed results are shown below.
Email Results:
Successful Display Failure Display Successful Display Failure Display
EMAIL ENABLED EMAIL DISABLED FROM ADDR SENT FROM ADDR FAILED
LINK OK LINK ERROR DEST ADDR SENT DEST ADDR FAILED
SMTP SERVER OK INVALID SERVER DATA MODE SENT DATA MODE FAILED
DEST ADDRESS OK DEST ADDR FAILED MESSAGE SENT MSG SEND FAILED
CONNECTING CANNOT CONNECT DISCONNECTED DISCONNECT FAIL
AUTH MODE SENT AUTH MODE FAILED EMAIL SUCCESS
PASSWORD SENT BAD PASSWORD (or USERNAME)
Activate Cell
To begin the cellular activation for a 463C Interface Module, verify that the 463C has been added to panel
programming using Remote Link or by calling Customer Service (1-800-641-4282). Next, press any top row
Select key when ACTIVATE CELL is displayed on the keypad. When the SURE NO YES? confirmation menu
appears press the Select key beneath YES to complete the cellular activation.
Note: This option only displays if a 463C Interface Module is attached to the panel.
Successful Display Failure Display
CELL ACTIVATED NOT ACTIVATED
SIGNAL: ▐▐▐▐▐▐▐
CONTINUE? NO YES
-XX dBm
SIGNAL: ▐▐▐▐▐▐▐
