Digital Monitoring Products XR500 Series Canadian Programming Guide
54
ZONE INFORMATION
1100 Series Key Fobs
For an 1100 Series Key Fob set the House Code from 1 to 50. See House Code programming in System
Options. Only zones 400 to 449 can be programmed as 1100 Series Key Fob zones. Refer to the 1100
Series Key Fob Programming Sheet (LT-0706) supplied with the 1100X Wireless Receiver and the 1100 Series
Key Fob Install Guide (LT-0703) as needed.
To operate arming and disarming properly, the Key Fob should be assigned to a User Number with
appropriate area assignments, however, the User Number does not have to exist at the time the Key
Fob is programmed. The Key Fob User Number can be added later by the User.
The following programming continues from the Zone Number section when zone 400-449 is selected.
19.11.1
KEY FOB USER
NUMBER: XXXX
Key Fob User Number
Enter the User Number (1-9999) used to identify the key fob user and their
arming and disarming authority. Default is blank.
USER XXXX
NOT IN USE
Displays when the User Number entered does not exist in User Code
programming. The key fob can be added, but the user must eventually be
added to cause the key fob to operate.
19.11.2
TRANSMITTER
SERIAL#: XXXXXXXX
Key Fob Serial Number
E nter the eight-digit serial number found on the wireless device.
19.11.3
TRANSMITTER
SUPRVSN TIME: 0
Key Fob Supervision Time
Press any top row key to select the supervision time required for the key fob
zone. Press COMMAND to accept the default time. Default is 0 for key fobs.
SELECT MINUTES:
0 60 240
Press the Select key under the required number of minutes. The key fob must
check in at least once during this time or a missing condition is indicated for
that zone. 1100 Series key fobs automatically checkin based on the supervision
time selected for the wireless zone, no additional programming is needed.
Zero (0) indicates an unsupervised transmitter.
Note: When the panel is reset or a receiver is installed or powered down and
powered up, the supervision timer restarts for all wireless zones.
19.11.4
NO. OF KEY FOB
BUTTONS: X
Number of Key Fob Buttons
Enter the number of buttons (1, 2, or 4) on the key fob being programmed.
Note: If the key fob is a one-button model, programming continues at the
Button Action section. Default button assignment for one-button key fobs is a
Panic Alarm (PN) with no output assigned.
19.11.5
BUTTON:
TOP BTM LFT RGT
Key Fob Button Selection (Four Buttons)
This prompt only displays if the key fob being programmed is a four-button
model. Press the Select key under the key fob button to program. The
following list identifies the default button assignments:
TOP Arming with no areas assigned
BTM Disarming with no areas assigned
LFT Panic Alarm (PN) with no output assigned
RGT Arming with Area 1 assigned
19.11.6
BUTTON:
TOP BTM
Key Fob Button Selection (Two Buttons)
This prompt only displays if the key fob being programmed is a two-button
model. Press the Select key under the key fob button to program. The
following list identifies the default button assignments:
TOP Arming with no areas assigned
BTM Disarming with no areas assigned
