Unit specifications
Dimensions Matrix Pro 570GS 16.15 x 14.91 x 5.84 cm
Matrix Pro 840GS 27.0 x 18.0 x 6.0 cm
Weight Matrix Pro 570GS 0.794 kg
Matrix Pro 840GS 1.06 kg
Connector Power/CAN 8 pin Conxall
Camera 5 pin Conxall
Speed/Status 8 pin Conxall
WARNING! Some original Matrix consoles have a 4 pin conxall
cable connection. The 4-pin and 8-pin cables are NOT
interchangable.
Environmental Storage -10 to +70°C
Operating 0 to +50°C
Humidity 90% non-condensing
Display Matrix Pro 570GS 320 x 240 resolution
14.5 cm
Matrix Pro 840GS 800 x 600 resolution
21.3 cm
Input/output USB 2.0
Power requirement < 9 watts @ 12 VDC
Copyrights
© 2013 TeeJet Technologies. All rights reserved. No part of this document or the computer programs described in it may be reproduced,
copied, photocopied, translated, or reduced in any form or by any means, electronic or machine readable, recording or otherwise, without
prior written consent from TeeJet Technologies.
Trademarks
Unless otherwise noted, all other brand or product names are trademarks or registered trademarks of their respective companies or
organizations.
Limitation of liability
TEEJET TECHNOLOGIES PROVIDES THIS MATERIAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR
IMPLIED. NO COPYRIGHT LIABILITY OR PATENT IS ASSUMED. IN NO EVENT SHALL TEEJET TECHNOLOGIES BE LIABLE FOR
ANY LOSS OF BUSINESS, LOSS OF PROFIT, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS, OR FOR INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF ANY KIND, EVEN IF TEEJET TECHNOLOGIES HAS BEEN ADVISED
OF SUCH DAMAGES ARISING FROM TEEJET TECHNOLOGIES SOFTWARE.
