CHApTER 3 – JObs / HOME sCREEN
Once the power up sequence has completed, the Home screen will appear with the option to start a new job or continue an existing job.
The console must have GPS before starting or continuing a job.
Setup for the specific machine and its components must be completed before starting a job. Once a
job is active, some setup options are not available to be changed. See the Unit setup mode menu structure chart in the introduction
chapter for details.
To change between simple mode and advanced mode, see the configuration chapter under Data management –> Options.
Simple mode
In simple mode, only one job will be available at a time. Only bounded area, coverage areas and application time are displayed on the
home screen. Only the current job is available for saving in Reports. Use with Fieldware Link is not available.
Figure 3-1: Simple mode home screen
Advanced mode
In advanced mode, more than one job will be available at any time. Client, farm, field and job names; bounded and coverage areas;
application time; and distance from selected job are displayed on the home screen. Of the names, only the job name can be entered
using the console. All saved jobs can be made into a PDF, SHP or KML file in Data->Reports. With Fieldware Link, a user can input
client, farm and field data as well as duplicate/edit jobs for reuse of boundaries and guidelines. Client, Farm and Field information can
only be inputted using Fieldware Link.
Figure 3-2: Advanced mode home screen
