CHApTER 4 – FULL sCREEN VidEO ViEw
RealView full screen video view allows live video input to be displayed. View video feed(s) and setup cameras without GPS available.
Options for RealView guidance are not available on this screen.
If a Video selection module (VSM) is installed on the system, two (2) video options are available:
►Single camera view – one (1) of up to eight (8) camera inputs can be selected to change the view of the video input.
►Split camera view – one (1) of two (2) sets of four (4) camera inputs (A/B/C/D or E/F/G/H) can be selected to divide the
screen into four separate video feeds.
Also available is:
►RealView camera snapshot – saves a still photo of the current view on the screen to a USB drive
1. Press REALVIEW CAMERA FULL SCREEN VIDEO VIEW bottom tab .
Figure 4-1: RealView Camera Full Screen Video View
