Programming Overview 151274-L8
6-12
6.5 Programming Menu Quick Reference
This section of the manual lists all Program Menu options in the order they appear on the sub-menus. Default
settings are indicated in text or marked with an asterisk. The comments column provide quick information and a
reference to a section (if applicable) which has more detailed information.
Menu Options/Defaults Comments
Module
Edit Module Select Module Enter Module ID Enter Module Name
Edit Module
Settings (If
applicable)
Section 7.2.1
Add Module
5824-Ser/Par/IO
Section 7.2.2
5860-LCD Ann
5895XL-Pwr Sup
5496-NAC Expand
5880-LED/IO Dev
5865-LED Annunc
Delete Module List of Modules Section 7.2.3
View Module List List of Modules Section 7.2.4
Zone
Edit Zone Select Zone to Edit
Edit Zone Name Section 7.3.1.1
Zone Properties
Verification Type
*1 Count
Section 7.3.1.2
2 Count
Alarm Ver.
PAS
SNGL ILOCK
DBL ILOCK
Heat Temp Set
135° to 150°F*
SD Devices. Section
7.3.1.2
135° to 190°
150°F* SK Devices. Section
7.3.1.2
Zone Outputs
Manual Pull (MP)
*Groups 01, 125;
Pattern 00
Section 7.3.1.3
Section 7.3.1.4
Water Flow (WF)
Detector Alarm (DE)
Aux 1 (A1)
no group Aux 2 (A2)
Pre-alarm (PR)
Fire Supervisory
(SU) (Group 124;
Pattern 00)
Trouble (TR)
no group
Status Point (SP)
CO Alarm (CO)
*Groups 01, 125;
Pattern 00
CO Supervisory
(Sco) * Group 124;
Pattern 00
Zone Accessry Opt
Cadence 00-16, 23; *02
SD Devices. Sections
7.3.1.4, 7.3.1.5
Fire Cadence 00, 01, *02, 23 SK Devices. Sections
7.3.1.4, 7.3.1.5
CO Cadence 00, 01, 02, *23
Local Zone Y or *N Section 7.3.1.5
Add Zone Section 7.3.2
Delete Zone Select Zone to Delete Section 7.3.3
View Zone Points Select Zone to View Section 7.3.4
