2 facp connection, 2 facp connection -15 – SilentKnight 5808 User Manual
Page 44
IntelliKnight 5808 Installation Manual
151274-L8
4-15
number.
Figure 4-17 5880 Board Layout
4.7.2
FACP Connection
The 5880 connects to the panel via the SBUS. Make connections as shown in Figure 4-18. After the 5880 is
connected to the panel, it must be added to the system. This programming step is described in Section 4.9.
Figure 4-18 5880 Connection to Main Control Panel Assembly
SBUS Connection
Dry Contact Inputs - Supervised/Power Limited
SBUS Address
DIPs
Supervised
Power Limited
