IntelliKnight 5808 Installation Manual 151274-L8
7-17
SLC
(cont.)
SWITCH
(cont.)
PAS_ACK Positive acknowledge switch. This switch
must be used in zones programmed as
Positive Alarm Sequence (see Table 7-1).
If an acknowledge switch closes when an
alarm or trouble condition is not already in
progress, a trouble will occur.
You must use a UL listed normally open,
momentary switch type. The switch must be
rated at 5V, 100 mA (minimum) and be used
with an EOL resistor for supervision.
ZN_AUX1 Latching Use these switch types if you want to monitor
special zone-level conditions (such as
operation of a fan or damper).
Non Latching
ZN_AUX2 Latching
Non Latching
SYS_AUX1 Latching Use these switch types if you want to monitor
special system-wide conditions (such as
operation of a fan or damper).
Non Latching
SYS_AUX2 Latching
Non Latching
DETECT SW Used to monitor conventional 4-wire
detectors, a contact closure will generate a
detector alarm event.
TAMPER Latching Performs identically to a supervisory switch,
but will be indicated as a tamper switch on the
LCD annunciator.
Non Latching
MAN REL Manual release switch, typically a pull station.
ILOCK Interlock release switch input.
CO DETECT SW CO Detector Switch
STATUS PT Status Point Switch
NOTIF
OUTPUT PT Select Group
AUX CONST Use for auxiliary power applications where
the devices require constant power.
AUX RESET Use for auxiliary power, resettable
applications. See Section 4.11.2 for a
description of how this option operates.
AUX DOOR Use for auxiliary power, door holder
applications. For example, if you were using
an auxiliary power supply for door holders,
you would use this option. See Section
4.11.2.1 for a description of how this option
operates.
Table 7-5 Point Programming
Module Type
Type
Selection
Function
Latching
Option
Comments
