N 7.5.2, Section 7.5.2 – SilentKnight 5808 User Manual
Page 110
Programming
151274-L8
7-18
7.5.2
Point Programming For Internal or External Power Module
To program for an internal or external power module points, follow these steps:
1.
Enter the installer code.
2.
Select 7 for Program Menu.
3.
Press 4 to enter point menu.
4.
Press the
or
arrows to select the desired module, then press
ENTER
. Refer to Section 6.5 for avail-
able choices.
5.
Enter the number of the circuit or point you wish to edit, then press
ENTER
. Refer to Table 7-6 for available
selections.
6.
Select the type by pressing the
or
arrows, then press
ENTER
.
7.
Select the function by pressing the
or
arrows, then press
ENTER
.
8.
Select the group by pressing the
or
arrows, then press
ENTER
.
9.
Edit point name, or press
to skip point name edit. See Section 7.5.4.
SLC
(cont.)
RELAY
OUTPUT PT
Select Group
Output Point, a general use relay type. Use
for applications requiring a relay, such as fan
shutdown, elevator recall, and so on.
AUX RESET
Select Group
Use for auxiliary power, resettable
applications. See Section 4.11.2.3 for a
description of how this option operates.
AUX DOOR
Select Group
Use for auxiliary power, door holder
applications. For example, if you were using
an auxiliary power supply for door holders,
you would use this option. See Section
4.11.2.1 for a description of how this option
operates.
SLC LED
Select LED
No.
UNUSED
NOTIF
When NOTIF is selected you must then select
the output group number.
Table 7-5 Point Programming
Module Type
Type
Selection
Function
Latching
Option
Comments
