IntelliKnight 5808 Installation Manual 151274-L8
3-7
SLC Accessories
B200SR Sounder Base
(99 max.)
Aux Pwr Standby: .5 mA mA
Alarm: 35 mA mA
SLC Alarm: .7 mA mA
B200S Sounder Base
Aux Pwr Standby: .5 mA mA
Alarm: 35 mA mA
SLC Alarm: .7 mA mA
B200SR-LF Low Frequency Sounder
Base
Aux Pwr Standby: 1 mA mA
Alarm: 125 mA mA
B200S-LF Low Frequency Sounder
Base
Aux Standby .55 mA mA
Alarm (high vol) 140 mA mA
SLC Standby .30 mA mA
B224RB Relay Base Standby/Alarm: .5 mA mA mA
RTS151/151 KEY Alarm: 7.5 mA mA
RA100Z Alarm: 10 mA mA
SLC Isolator Devices
SK-ISO (Isolator Module)
(100 max.)
Standby/Alarm: .45 mA mA mA
B224BI Isolator Base Standby/Alarm: .5 mA
Accessories Modules
5860 Remote Fire Alarm Annunciator (12 max)
Standby: 20 mA mA
Alarm: 25 mA mA
5824 Serial / Parallel Module (2 max.) Standby/Alarm: 45 mA mA mA
5496 Notification Power Expander
(8 max.) Standby/Alarm: 10 mA mA mA
5895XL Intelligent Power expander (8 max.) Standby/Alarm: 10 mA mA mA
5865-4 LED Annunciator
(with reset and silence switches)
(8 max.)
Standby: 35 mA mA
Alarm: 145 mA mA
5865-3 LED Annunciator
Standby: 35 mA mA
Alarm: 145 mA mA
5880 LED I/O Module
Standby: 35 mA mA
Alarm: 200 mA mA
5883 Relay Interface (32 max.)
Standby: 0 mA mA
Alarm: 220 mA
(22 mA per
relay)
mA
A Total System Current
Auxiliary Devices 2 Refer to devices manual for current rating.
Alarm/Standby: mA mA mA
Alarm/Standby: mA mA mA
Alarm/Standby: mA mA mA
Alarm/Standby: mA mA mA
B Auxiliary Devices Current
Notification Appliance Circuits Refer to devices manual for current rating.
Alarm: mA mA
Alarm: mA mA
Table 3-2: Current Draw Worksheet for SK Devices
Device
Number
of
Devices
Current per Device
Standby
Current
Alarm
Current
