Before You Begin Installing 151274-L8
3-6
SK-Photo
(99 max.) 1
Standby/Alarm: .30 mA 6
mA mA
SK-Photo-T mA mA
SK-Ion mA mA
SK-Heat mA mA
SK-Heat-HT mA mA
SK-Duct (includes PhotoR)
5
SK-Acclimate mA mA
SK-Heat-ROR mA mA
SK-Beam (without integral test) SLC Standby/Alarm: 2 mA
Aux. Pwr Standby: 2 mA mA
Alarm: 8.5 mA mA
SK-Beam-T (with integral test)
4 SLC Standby/Alarm: 2 mA
Aux. Pwr Standby: 2 mA mA
Alarm: 8.5 mA mA
SK-FIRE-CO SLC Standby: .30 mA mA
Alarm: 7.2 mA mA
Addressable SLC Devices
SK-Monitor
(99 max.)
1
Standby/Alarm: .375 mA mA mA
SK-Minimon mA mA
SK-Pull-SA/SK-Pull-DA mA mA
SK-Monitor-2 Standby/Alarm: .75 mA mA mA
SK-Mon-10 Standby/Alarm: 3.5 mA mA mA
SK-Control SLC Standby: .375 mA
Alarm: .375 mA mA
mA
Aux.
Power Standby: 1.7 mA mA
Alarm: 7 mA mA
SK-Control-6 SLC Standby: 2.25 mA
Alarm: 2.25 mA mA
mA
Aux. Pwr Standby: 8 mA
Alarm: 20 mA mA
mA
SK-Relay Standby/Alarm: .255 mA mA mA
SK-Relay-6 Standby/Alarm: 1.45 mA mA mA
SK-RelayMon-2 Standby: 1.3 mA mA
Alarm: 24 mA mA
SK-Zone
(99 max.) 1
Aux Pwr Standby: 12 mA mA
Alarm: 90 mA mA
SLC Standby/Alarm: .27 mA mA mA
SK-Zone-6
Aux Pwr Standby: 50 mA mA
Alarm: 270 mA mA
SLC Standby/Alarm: 2 mA mA mA
Table 3-2: Current Draw Worksheet for SK Devices
Device
Number
of
Devices
Current per Device
Standby
Current
Alarm
Current
