background image

MAXQ Family User’s Guide:

MAXQ8913 Supplement

20-3

20.2.3 DAC 3 Output Register (DAC3OUT, M3[04h])

Bits 7:0: DAC 3 Output Value. This register sets the voltage output value for the DAC3 channel between zero
(DAC3OUT = 00000000b) and full scale (DAC3OUT = 11111111b). For this register value to be effective, DACEN.2
(DACEN3) must be set to 1 to enable the voltage output at pin DAC3. If DACEN3 = 0, the value stored in this register
has no effect on the voltage level of pin DAC3.

20.2.4 DAC 4 Output Register (DAC4OUT, M3[05h])

Bits 7:0: DAC 4 Output Value. This register sets the voltage output value for the DAC4 channel between zero
(DAC4OUT = 00000000b) and full scale (DAC4OUT = 11111111b). For this register value to be effective, DACEN.3
(DACEN4) must be set to 1 to enable the voltage output at pin DAC4. If DACEN4 = 0, the value stored in this register
has no effect on the voltage level of pin DAC4.

20.2.5 Current Sink Control Register (ISINKCN, M3[07h])

Bits 15:8: Current Sink 2 Output Value (ISINK2.[7:0]). Bits 15 to 8 in this register set the operating mode for current
sink output 2 (SINK2) as follows.
• ISINK2 = 00h. Current output SINK2 is disabled.
• ISINK2 = (01h to FFh). Current output SINK2 is enabled, with a current sink capability given by

I

SINK2

= ISINKCN[15:8] x 62.5FA

Bits 7:0: Current Sink 1 Output Value (ISINK1.[7:0]). Bits 7:0 in this register set the operating mode for current sink
output 1 (SINK1) as follows.
• ISINK1 = 00h. Current output SINK1 is disabled.
• ISINK1 = (01h to FFh). Current output SINK1 is enabled, with a current sink capability given by

I

SINK1

= ISINKCN[7:0] x 62.5FA

Bit #

7

6

5

4

3

2

1

0

Name

DAC3OUT

Reset

0

0

0

0

0

0

0

0

Access

rw

rw

rw

rw

rw

rw

rw

rw

Bit #

7

6

5

4

3

2

1

0

Name

DAC4OUT

Reset

0

0

0

0

0

0

0

0

Access

rw

rw

rw

rw

rw

rw

rw

rw

Bit #

15

14

13

12

11

10

9

8

Name

ISINK2

Reset

0

0

0

0

0

0

0

0

Access

rw

rw

rw

rw

rw

rw

rw

rw

Bit #

7

6

5

4

3

2

1

0

Name

ISINK1

Reset

0

0

0

0

0

0

0

0

Access

rw

rw

rw

rw

rw

rw

rw

rw

Maxim Integrated
