6BChapter 7: Playing back a recording
50 TruVision NVR 50 User Manual
Figure 22: Playback window
1. Playback viewer.
2. Camera panel. Select the cameras for
playback. Move the mouse over the area to
display the list of cameras available.
3. Calendar panel.
Blue: Current date
Green/Yellow/Red: Recordings available
on the NVR.
4. Playback control toolbar. See Figure 23.
The playback control toolbar
It is easy to manually control playback using the playback control toolbar. See
Figure 23 below.
Note: The control toolbar does not appear for instant playback.
Figure 23: Playback control toolbar (all-day playback example shown)
Item Description
1. Audio and video control toolbar:
/ Audio on/off.
/ Start/stop a video clip during playback. Sections of a recording can be
saved to an external storage device.
Add default bookmark
Add customized bookmark
