20BAppendix D:
KTD-405 keypad
TruVision NVR 50 User Manual
147
8. Press
. The main menu appears.
Example 2: To modify a menu option using the keypad
1. In the main menu press and hold
esc
and then press the arrow buttons to
navigate to the desired menu icon (for example, Display Mode Settings).
2. Press esc and
to go to setup menu.
3. Press
Zoom +
or
Zoom -
to scroll to the menu tab,
More Settings
.
4. When in the desired menu screen, press and hold
esc
and then press the
arrow buttons to navigate the cursor to the option,
Menu Timeout
.
5. Press
to activate the dropdown menu.
6. Press and hold
esc
and then press the up/down arrow buttons to navigate to
the desired option.
7. Press
to select the option.
8. Press and hold
esc
and then press the up/down arrow buttons to navigate to
Apply. Press
to select it. Then navigate to
Back
to return to live view.
Instead of the arrow buttons, you can also use the joystick on the keyboard.
TVN 50 mapping to the KTD-405 keypad
Table 22: TVN 50 mapping to the KTD-405 keypad
Task
Keypad action
Further information
Menu mode
Call up or exit menu
In live view, press
esc
.
To exit the menu: go to the
Power Manager menu and select
Logout.
Move through the menus
Press and hold
esc
and
then press the arrow
buttons or use the joystick.
Down
,
Up
,
Left
,
Right
Move between menu tabs
Press Zoom + or Zoom - to
switch between menu tabs.
Navigate to a menu option
Press and hold
esc
and
then press the arrow
buttons.
Down
,
Up
,
Left
,
Right
Select a character or menu
option
Press
Enter
(
).
Note. If you press
esc
before
pressing
Enter
, you quit the
menu without saving any
changes. It is the same as
cancel.
Select the zone ID
Press
zone
to connect the
keypad to the NVR and
enter the Zone ID.
