MINI-MAX Ultrasonic Bolt Tension Monitor

19) Press the

ENTER key to display the Digits Edit Box.

Note: Enter the temperature coefficient value of the bolt that was

documented in the previous section. Reminder: The value was written

down and scribed on the side of the bolt. It is the temperature coefficient

used for the probe zero bolt.

20) Press the

UP and DOWN arrow keys to scroll the highlighted value.

21) Press the

LEFT and RIGHT arrow keys to scroll the digit locations.

22) Repeat steps

20 & 21 until the TEMP COEF value is correctly

displayed.

23) Press the

OK key to return to the One Point Zero List, or ESC to

cancel entering the

TEMP COEF value.

24) Use the

UP and DOWN arrow keys to scroll through the One Point

Zero List Items until ULTRASONIC LEN is highlighted.
