Dakota Ultrasonics

108

Storing the Reference Length

7) Press the

MEAS key once to activate measure menu items. Press the

MEAS key multiple times to move right and the ESC key multiple times

to move left until the

LOC cell is highlighted.

8) Press the

ENTER key to display the Group View Box.

9) Press the

UP, DOWN, LEFT, and RIGHT arrow keys to scroll the target

cell cursor to the desired storage location.

Note: The first column must be used to store reference lengths.

Selecting the Calibration Mode (Vector or Regression)

1) Press the

MENU key multiple times to tab right and the ESC key

multiple times to tab left until the

CAL menu is highlighted and

displaying the submenu items.
