Page 49

MINI-MAX Ultrasonic Bolt Tension Monitor

3) Use the

UP, DOWN, LEFT, & RIGHT arrow keys to highlight the

appropriate alpha characters.

4) Press the

ENTER key to select a character and advance to the next field

of the

Group Note.

5) Use the

CLR key to backspace if necessary.

6) Repeat steps

3 through 5 until the Group Note is completed.

7) Press the

OK key to save the Group Note and return to the Group List

Items menu, or ESC to cancel entering the Group Note.

Selecting the Number of Bolts in the Group

Note: A group can contain up to 250 bolts. There must be at least 1 bolt in

a group. If multiple bolts will be used to zero the MINI-MAX, you will need

to create multiple bolts in the group. In some cases the user will opt to use

a bolt that is a representative bolt from each application, rather than just an

arbitrary bolt. This would typically be done in critical applications.
