MINI-MAX Ultrasonic Bolt Tension Monitor

Chapter 4 Keyboard, Menu, & Connector
Reference

4.1 Menu Key (Operation & Sub Menus )

The

Menu key activates the primary menu structure containing 10 menu tab

groups. These tab groups then contain sub menu items, or functions. The sub
menu items have been organized in tab groups according to how closely they are
related to the individual tab group names. Let’s first get familiar with how to
move around in these tabs before continuing on to the sub menu functions. This
procedure is outlined below:
