Boot Loader Commands
72 Command Set
Get Current Program (0Ch)
The Get Current Program command returns a code for the current program being
executed in the module. These codes are defined as follows:
To get the current program command, send the following to the module:
The module responds as follows, indicating that it is a M5e/M5e-Compact application
program:
Error Status Codes
FAULT_MSG_WRONG_NUMBER_OF_DATA – 100h
Write Flash Sector (0Dh)
The Write Flash Sector command is the same as the old Write Flash (01h) except it
has an extra flash sector argument. This allows future Mercury Embedded products to
work with the same command set.
Code Program
0x11 M5e/M5e-C Bootloader
0x12 M5e/M5e-C Application
FF 00 0C 1D 03
SOH Length OpCode CRC
FF 01 0C 00 00 12 63 43
SOH Length OpCode Status Program CRC
FF 0F 0D 02 25 44 10 00 00 00 00 02 12 34 56 78 90 12 73 4C
SOH Lengt
h OpCod
e Password Start Address Sector Data To Write CRC
